No. |
Part No. | Part Name |
Qty |
|
1 |
Q150B1018 | Screw |
20 |
|
2 |
WG9231340002 | Screw |
4 |
|
3 |
WG9231340001 | Cover |
2 |
|
4 |
WG9012340011 | Bolt |
2 |
|
5 |
AZ9231340128 | Planetary carrier |
2 |
| 199112340029 | Planetary carrier |
2 |
|
|
6 |
Q2541025 | Screw |
8 |
|
7 |
190003330148 | Ball |
10 |
|
8 |
WG9231340130 | Bolt |
10 |
| WG9012340004 | Bolt |
10 |
|
|
9 |
WG9231340129 | Needle |
20 |
| WG99-934-013 | Needle |
20 |
|
|
10 |
WG9231340131 | Washer |
10 |
| WG9012340075 | Washer |
10 |
|
|
11 |
WG9231340132 | Washer |
10 |
| WG9012340077 | Washer |
10 |
|
|
12 |
WG9231340122 | Planet gear |
10 |
| WG9012340122 | Planet gear |
10 |
|
|
13 |
190003933351 | Circlip |
2 |
|
14 |
WG880 410097 | Washer |
2 |
|
15 |
WG9231340121 | Sun gear |
2 |
| WG9012340005 | Sun gear |
2 |
|
|
16 |
WG9012340076 | Washer |
2 |
|
17 |
WG9003884160 | Nut |
20 |
|
18 |
WG880420027 | Oil drip pan |
2 |
|
19 |
Q151C1295TF2 | Screw |
10 |
|
20 |
190003901704 | Cyl.pin |
10 |
|
21 |
WG9231340223/224 | Drive axle left/Drive axle right |
1 |
|
22 |
WG680340016~19.186.187 | Shim |
null |
|
23 |
WG680340015 | Securing sheet |
2 |
|
24 |
WG880420034 | Securing ring |
2 |
|
25 |
WG9231340125 | Support for intermed.ring gear |
2 |
| WG9112340021 | Support for intermed.ring gear |
2 |
|
|
26 |
WG9231340123 | Intermed.ring gear |
2 |
| WG9012340121 | Intermed.ring gear |
2 |
|
|
27 |
WG880420014 | Srap ring |
2 |
|
28 |
190003326167 | Roller bearing |
2 |
|
29 |
WG9012340029 | Gasket |
4 |
|
30 |
199112340011 | Rear wheel hub C |
2 |
|
31 |
WG9012340021 | Oil drip pan |
2 |
|
32 |
WG9012340020 | Gasket |
2 |
|
33 |
Q40308 | Spring washer |
20 |
|
34 |
Q150B0816 | Screw |
20 |
|
35 |
WG9012340017 | Spacer ring |
2 |
|
36 |
WG9112340113 | Gasket |
2 |
|
37 |
WG9112340114 | Gasket |
2 |
|
38 |
WG9112340006 | Brake grum |
2 |
|
39 |
AZ9231340200 | Brake shoe& lining C |
4 |
|
40 |
WG9231342015 | Spring |
2 |
|
41 |
WG9112340049 | Spring |
4 |
|
42 |
WG9000340027 | Pressure roller |
4 |
|
44 |
199000340064 | Brake shoe pin |
4 |
|
45 |
Q5280624 | Pin |
4 |
|
46 |
WG9231340226/227 | Brake camshaft |
1 |
|
47 |
WG880440010 | Shim |
4 |
|
48 |
WG880340023 | “O” ring |
2 |
|
49 |
WG9100340017 | Bush |
4 |
|
50 |
Q151B1645TF2 | Screw |
4 |
|
51 |
AZ9231340556 | Bracket |
2 |
|
52 |
Q151B1635TF2 | Screw |
16 |
|
53 |
AZ9231340562 | Brake anchor |
2 |
|
54 |
190003933300 | Circlip |
2 |
|
55 |
199112340012 | Brake cover |
2 |
|
56 |
WG880340037 | Gasket |
8 |
|
57 |
Q40308 | Spring washer |
12 |
|
58 |
Q150B0816 | Screw |
12 |
|
59 |
WG9112340010 | Bush |
2 |
|
60 |
190003963112 | Grease nipple |
2 |
|
61 |
WG880340031~34 | Shim |
null |
|
62 |
199014340041 | Bracket |
2 |
|
63 |
Q151B1445 | Screw |
2 |
|
64 |
Q151B1490 | Screw |
2 |
|
65 |
WG9100340056/57 | Adjusting device left/right |
1 |
|
66 |
WG880340022 | Washer |
1 |
|
67 |
WG80 320028~30.46 | Shim |
null |
|
68 |
190003933116 | Circlip |
1 |
|
69 |
190003326067 | Roller bearing |
2 |
|
70 |
WG9012340027 | Gasket |
2 |
