| No. | Part No. | Part Name | Qty | Remark |
|---|---|---|---|---|
| 1 | WG2229100125 | Flattened Round Wire Snap Ring For Hole (For Inner Gear Ring ) |
1 | |
| Original Part | WG2229100125 | Flattened Round Wire Snap Ring For Hole (For Inner Gear Ring ) |
1 | |
| Replacement Part | AZ2229100125 | Flattened Round Wire Snap Ring For Hole (For Inner Gear Ring ) |
1 | |
| 2 | WG9003326020 | Antifriction Bearing 6020 Gb / T276 |
1 | |
| 3 | WG2229100005 | Sun Gear Gasket (Front) | 1 | |
| 4 | WG2210100005 | Internally Toothed Annulus | 1 | |
| 5 | AZ2203100131 | Sun Gear And Sleeve Assembly | 1 | |
| 6 | WG2229100006 | Sun Gear Gasket (Rear) | 1 | |
| 7 | AZ2203100002 | Planetary Carrier Assembly | 1 | |
| 8 | WG9003991125 | Flattened Round Wire Snap Ring For Hole |
1 | |
| Original Part | WG9003991125 | Flattened Round Wire Snap Ring For Hole |
1 | |
| Replacement Part | AZ9003991125 | Flattened Round Wire Snap Ring For Hole |
1 | |
| 9 | WG9003321820 | Antifriction Bearing 61820 Gb / T276 |
1 | |
| 10 | WG2229100032 | Spacer Bushing | 1 | |
| 11 | WG2212100001 | Planetary Shaft | 5 | |
| 12 | Q5280430 | Elastic Cylindrical Pin | 5 | |
| 13 | Q5280630 | Elastic Cylindrical Pin | 5 | |
| 14 | WG2229100008 | Planetary Gear Gasket | 10 | |
| 15 | WG2210100004 | Planetary Wheel | 5 | |
| 16 | AZ220310000006 | Low-Gear Tapered Hub Assembly | 1 | |
| 17 | WG2229100002 | Torque Sleeve | 9 | |
| 18 | WG9003801045 | Q1841240TF2 Pre-Coated Thread Locking Glue |
9 | |
| 19 | WG2229020001 | Synchronous Pushing Block | 9 | |
| 20 | WG2229020002 | Pushing Block Outer Spring | 9 | |
| 21 | WG2229020003 | Pushing Block Inner Spring | 9 | |
| 22 | WG9003326322 | Rolling Bearing 63 / 22 Gb / T276 |
1 | |
| 23 | WG2210100007 | Range-Gear Synchronous Gear Block |
1 | |
| 24 | WG2210100109 | Range Gear Synchronizer Ring | 2 | Wear Part |
| 25 | WG9003991130 | Elastic Snap Ring For Shaft | 1 | |
| Original Part | WG9003991130 | Elastic Snap Ring For Shaft | 1 | |
| Replacement Part | AZ9003991130 | Elastic Snap Ring For Shaft | 1 | |
| 26 | WG2210100006 | Gear Ring Bracket | 1 | |
| 27 | WG2210100059 | Range Gear Synchronous Sliding Sleeve |
1 | |
| 28 | WG2203100006 | High-Gear Tapered Hub Assembly | 1 | |
| 29 | WG2203100007 | Guide Ring Assembly | 1 | |
| 30 | WG2220100008 | Transmission Rear Housing | 1 | |
| 31 | WG9003326218 | Antifriction Bearing 6218 Gb / T276 |
1 | |
| 32 | Q402B08 | Large Washer | 1 | |
| 33 | Q1840820 | Hexagon Bolt With Flange | 1 | |
| 34 | WG2229100167 | Cover Plate Gasket | 1 | Service Replacement Part |
| 35 | Q1841225 | Hexagon Bolt With Flange | 4 | |
| 36 | AZ2203240209 | Filter Assembly | 1 | |
| 37 | AZ220324000017 | Oil Pipe Assembly | 1 | |
| 38 | WG9004130020 | Combination Sealing Washer | 2 | |
| 39 | AZ900396100023 | Hollow Bolt | 1 | |
| 40 | WG2229100073 | Bolt | 1 | |
| 41 | WG2229100072 | Pressure Plate | 1 | |
| 42 | WG2210100018 | Output Flange Φ180 End-Face Tooth |
1 | |
| 43 | WG2222100023 | Output Shaft End Cover (Double Oil Seal) |
1 | |
| 44 | WG9003801056 | Glued Bolt Q170B1055 | 1 | |
| 45 | Q40310 | Spring Washer | 1 | |
| 46 | WG9003801055 | Glued Combination Bolt Q1421055 |
7 | |
| 47 | WG2229100141 | Rear End Cover Gasket Of Output Shaft |
1 | Service Replacement Part |
| 48 | WG2210100174 | Sensor Gear Ring | 1 | |
| 49 | WG9003071105 | Combination Frame Oil Seal ( Inner Oil Seal , Outer Oil Seal) |
1 | |
| 50 | WG9003801065 | Glued Combination Bolt Q1421065 |
4 | |
| 51 | WG2222100009 | Range Gear Cylinder | 1 | |
| 52 | WG2229100189 | Range Gear Cylinder Paper Washer |
1 | Service Replacement Part |
| Original Part | WG2229100189 | Range Gear Cylinder Paper Washer |
1 | |
| Replacement Part | AZ2229100189 | Range Gear Cylinder Paper Washer |
1 | |
| 53 | AZ2208100003 | Adjusting Gasket Unit | 1 | |
| 54 | WG2229100039 | Range Gear Piston | 1 | |
| Original Part | WG2229100039 | Range Gear Piston | 1 | |
| Replacement Part | AZ2229100039 | Range Gear Piston | 1 | |
| 55 | WG2229100040 | Range Gear Piston O-Ring | 2 | |
| 56 | AZ9003870016 | Hexagon Nut M16×1.5 | 1 | |
| 57 | WG9003071700 | O-Ring 26500170 GB3452.1 | 1 | |
| Original Part | WG9003071700 | O-Ring 26500170 GB3452.1 | 1 | |
| Replacement Part | AZ9003071700 | O-Ring Seal | 1 | |
| 58 | WG2229230010 | Inner Hole Sealing Ring Of Split Gear Rear Housing |
2 | Wear Part |
| 59 | WG2214100002 | Range Gear Shift Fork Shaft | 1 | |
| 60 | WG2229100022 | Shift Fork Centering Block | 2 | |
| Original Part | WG2229100022 | Shift Fork Centering Block | 1 | |
| Replacement Part | AZ2229100022 | Shift Fork Centering Block | 1 | |
| 61 | WG2214100001 | Range Gear Shift Fork | 1 | |
| 62 | WG9003990024 | Waveform Elastic Washer | 2 | |
| 63 | WG2229100043 | Shift Fork Support Pin | 2 | |
| 64 | WG9003070800 | O-Ring 18000800 GB3452.1 | 1 | |
| 65 | WG9003321118 | Cylindrical Roller 11X18Ⅲb GB4661 |
120 | |
| 66 | WG2229100007 | Roller Spacing Piece | 15 | |
| 67 | WG9003991056 | Elastic Snap Ring For Hole | 1 | |
| Original Part | WG9003991056 | Elastic Snap Ring For Hole | 1 | |
| Replacement Part | AZ9003991056 | 1 |
